Wooden Side Rails - Classic Full-Length Safety Rails for Woburn Beds.
- Full-Length Set of 4 for Complete Rail Coverage - the Wooden Side Rails are supplied as a set of four full-length rails providing continuous coverage along both sides of the bed; full-length rails, as distinct from split or half-length rails, cover the entire lateral surface of the mattress from head to foot end, reducing the number of gap zones that exist at the transitions between rail sections where entrapment risk is higher; the MHRA entrapment assessment for full-length rails must confirm that the gap dimensions at the mattress-to-rail and headboard-to-rail junctions remain within compliance at the maximum mattress depth in use.
- Domestic Wooden Aesthetic for Care Home and Community Settings - the wooden construction matches the wooden frame of the Woburn, Community, and Community Low beds, creating a visually integrated bed unit that has the aesthetic of a domestic divan rather than a clinical hospital bed; this domestic appearance supports resident wellbeing and dignity per CQC Regulation 10, particularly for residents living long-term in care homes where the appearance of their sleeping environment contributes meaningfully to their sense of home and self-determination.
- Compatible with Bed Length Extension Kits - the Wooden Side Rails are compatible with the bed length extension kit accessories, allowing the rail coverage to be extended to match the extended platform when a length extension is fitted; the correct extended rail product must be selected when the bed is fitted with an extension to prevent the gap at the foot end of the rail that would arise if standard rails are used with an extended platform.
- Woburn Low, Community Low, and Community 1200 - MHRA Required - the rails are designed for Woburn Low, Woburn Community Low, and Woburn Community 1200 profiling beds; each rail use must be supported by an individual MHRA risk assessment documenting the clinical need and a best interest decision under the Mental Capacity Act 2005 where the resident lacks capacity; product code NCL-HLDWC110; CQC Regulation 12 equipment records must include the rail specification and bed model.
Wooden Side Rails - Full-Length Set of 4 - Woburn Low, Community Low, Community 1200 - MHRA Assessed
The Wooden Side Rails provide full-length lateral coverage along both sides of the Woburn Low, Woburn Community Low, and Woburn Community 1200 profiling beds in a set of four rails matching the beds' wooden frame aesthetic. Full-length construction minimises inter-section gap zones compared to split rails. Compatible with bed length extension kits for extended platform configurations. Each use requires MHRA individual risk assessment and, where relevant, a MCA 2005 best interest decision. NCL-HLDWC110.
Specifications
| Specification | Detail |
|---|---|
| Supply | Set of 4 full-length rails |
| Compatible Beds | Woburn Low; Woburn Community Low; Woburn Community 1200 |
| Material | Wooden - matches Woburn bed frame aesthetic |
| Extension Compatibility | Compatible with bed length extension kits |
| Reference | NCL-HLDWC110 |
| Compliance | MHRA bed rail safety guidance; Mental Capacity Act 2005; CQC Regulation 12 |
Regulatory Compliance
The Wooden Side Rails comply with MHRA bed rail safety guidance when correctly fitted and assessed. Individual risk assessment per MHRA guidance is mandatory before any rail is used; for residents lacking capacity, a documented best interest decision under the Mental Capacity Act 2005 is required. The maximum mattress depth must be confirmed compatible with the rail height to maintain MHRA entrapment zone compliance at the sleeping surface-to-rail top gap. Extension kit compatibility must be confirmed when an extended platform is in use. Equipment register records must include the rail specification, bed model, MHRA assessment date, and MCA decision where applicable for CQC Regulation 12 compliance.
Frequently Asked Questions
What is the clinical distinction between full-length rails and split rails, and when is each indicated?
Full-length rails, like the NCL-HLDWC110 set, extend the full length of the mattress from the headboard to the footboard on each side, providing a continuous lateral barrier with no gap zones between sections. Split rails consist of two shorter sections on each side - typically a head section and a foot section - with a gap between them at approximately the mid-point of the mattress. The clinical indication for each depends on the resident's risk profile and functional needs. Full-length rails provide maximum lateral containment and fewer inter-section gap zones, making them appropriate for residents with high nocturnal movement who need continuous lateral protection along the full mattress length. Split rails leave the mid-section of the mattress open at both sides, which is clinically indicated for residents who can perform self-initiated transfers from a sitting position at the mid-bed point without rail obstruction; for these residents, the split configuration maintains fall protection while preserving the ability to exit the bed independently from the unrailed section. The selection between full-length and split rails must be documented in the MHRA risk assessment based on the individual resident's clinical need and functional assessment.
Do wooden side rails require the same MHRA entrapment zone assessment as metal or plastic rails?
Yes. MHRA bed safety guidance applies to all side rails regardless of material, and the entrapment zone dimensions that must be assessed are the same for wooden rails as for metal or mesh rails. The material distinction between wooden and mesh rails affects the clinical functions of visibility (mesh allows carers to see through; wood does not) and the gap profile (wood provides a solid barrier; mesh allows airflow) but does not change the MHRA entrapment zone assessment requirements. The seven-zone MHRA assessment must be completed for wooden rails confirming the gap dimensions at the mattress-to-rail interface, the headboard-to-rail interface, between the mattress edge and the rail, and at the rail end zones. The mattress depth must be confirmed compatible with the wooden rail height so that the sleeping surface does not rise above the entrapment compliance threshold when the mattress is compressed under the resident's weight. The absence of a visibility function in a solid wooden rail is also a factor for the clinical assessment: carers cannot observe the resident through the rail during observation checks, which may be relevant for residents who require visible overnight monitoring.
